Solid dose inspection
APT Tablet 5
Add 360° tablet and capsule inspection to a counting and bottle-filling machine. APT Tablet 5 is a compact five-lane module that inspects products before filling and removes products that fail the inspection criteria.
Application
The module replaces the traditional vibrating product-feed board on a compatible counting and filling machine. A quick-change roller assembly supports cleaning and product changes, while the vision computer and controls can be integrated into the host machine or housed in an optional separate cabinet.
Key features
- Color inspection with automatic suction rejection across five lanes.
- Tool-free removal of the complete roller module for cleaning.
- Product recipes, batch records, audit trail and at least three user access levels.
Technical information
| Feature | Specification |
|---|---|
| Capacity | Up to 50,000 products/hour for the documented five-lane configuration; product dependent. |
| Inspection width | Up to 225 mm per camera/illumination unit. |
| Recipe storage | 50 product recipes; expanded storage optional. |
| Reject collection | Central reject container with at least 3 L volume. |
| Power and air | 230 V AC, 50 Hz; minimum 6 bar compressed air, specified air quality class 1 to ISO 8573.1. |
| Options | Mobile stainless-steel controls cabinet, additional format units, spare roller module and IQ/OQ documentation. |
System configuration, inspection capability and achievable output depend on the product, handling conditions and agreed application requirements. APT evaluates each application to define the appropriate inspection, integration and qualification scope.
